GS-C25 Flanged DIN Standard Bellow Seal Globe Valve

JOEPAI GS-C25 Flanged DIN Standard Bellow Seal Globe Valve made in China，Suitable for industries such as petrochemicals, fine chemicals, pharmaceuticals, metallurgy, and power plants, especially for closed conveying systems for toxic, harmful, flammable, and corrosive media. The unique dual sealing structure ensures long-term stable operation and is the preferred valve solution for fine chemicals and harsh working conditions.

Technical Specifications:

Pressure Rating: 1.0-4.0Mpa

Specification: DN15-DN500

Material: GS-C25,CF8,CF3

Standard flanges: DIN

Bellow Seal Globe Valve Detail:

Construction:  BB-BG-OSandY

Operation:  Manual, Pneumatic

Design Standard:  DIN3356

Face to Face Dimension:  DIN3202

Flange Ends:  DIN2543-2545

Test and Inspection:  DIN3230

Bellow Seal Globe Valve advantage:

1. The GS-C25 Flanged DIN Standard Bellow Seal Globe Valve has a simple structure and is easy to manufacture and maintain.

2. The working stroke of the globe valve is small and the opening and closing time is short.

3. The globe valve has good sealing performance, low friction between sealing surfaces, and a long service life.

The types of Bellow Seal Globe Valves are divided into external thread globe valves and internal thread globe valves according to the position of the valve stem thread. According to the flow direction of the medium, there are straight through globe valves, DC globe valves, and angle globe valves. Globe valves are divided into packing sealed globe valves and bellows sealed globe valves according to their sealing forms.

Main Materials:

Main Dimensions:
