Ball Valves

Ball Valves

View as

Stainless Steel Threaded Three-way Pneumatic Ball Valve

Stainless Steel Threaded Three-way Pneumatic Ball Valve

China JOEPAI's Stainless Steel Threaded Three-way Pneumatic Ball Valve is divided into L-shaped and T-shaped. The L-shaped three-way ball valve is suitable for switching the flow direction of the medium, which can connect two perpendicular channels. The T-shaped three-way ball valve is suitable for dividing, merging or switching the flow direction of the medium. The T-shaped hole can connect three channels to each other or two of them. The three-way ball valve generally adopts a two seat structure, and can also adopt a four seat structure according to user requirements.
Manual Stainless Steel Threaded Three Way Ball Valve

Manual Stainless Steel Threaded Three Way Ball Valve

Joepai manufactures manual stainless steel threaded three way ball valves ideal for industrial flow control. Made from corrosion-resistant stainless steel, these valves ensure long-lasting performance under high pressure and harsh conditions.They operate by rotating a handle to align the ball bore, directing flow between ports. The valves come in two types: L-Port (for flow diversion between two lines) and T-Port (for flow mixing or splitting).Suitable for chemical, HVAC, and water systems, these valves offer reliable sealing, easy installation, and durable operation at a competitive price.
Threaded 3-Way Ball Valve with ISO 5211 Direct Mounting Pad

Threaded 3-Way Ball Valve with ISO 5211 Direct Mounting Pad

JOEPAI Threaded 3-Way Ball Valve with ISO 5211 Direct Mounting Pad made in China has internal flow channels that can be divided into L-shaped and T-shaped channels. The internal valves are divided into PTFE seals and metal hard seals, and can be equipped with manual switches or worm gear switches. The above connection platform complies with ISO 5211 standard and can be directly matched with electric or pneumatic actuators for remote intelligent control of switches or adjustments.
Brass Mini Ball Valve With Aluminium Handle

Brass Mini Ball Valve With Aluminium Handle

The JOEPAI high quality Brass Mini Ball Valve With Aluminium Handle features a high quality brass forged valve body and an anodized aluminum handle design, providing excellent corrosion resistance and a lightweight operating feel. Compact structure suitable for scenarios with limited space or simple pipeline requirements, such as drinking water systems, small gas equipment, HVAC pipelines, etc
Stainless Steel Threaded Mini Ball Valve with Hose Nipples

Stainless Steel Threaded Mini Ball Valve with Hose Nipples

JOUPAI factory has been focusing on threaded mini ball valves for over 20 years.The Stainless Steel Threaded Mini Ball Valve with Hose Nipples is a valve designed specifically for installation in narrow spaces. It is made of corrosion-resistant stainless steel or brass and has reliable performance in medium and low pressure systems such as water, air, natural gas, and oil pipelines.
Pneumatic Actuated Cast Steel 2PC Flange Ball Valve

Pneumatic Actuated Cast Steel 2PC Flange Ball Valve

JOEPAI high quality Pneumatic Actuated Cast Steel 2PC Flange Ball Valve is mainly used to cut off or connect media in pipelines, and can also be used for fluid regulation and control. Among them, the hard sealed V-shaped ball valve has a strong shear force between its V-shaped core and the metal seat of the welded hard alloy, which is particularly suitable for media containing fibers, small solid particles, etc. The multi way ball valve on the pipeline can not only flexibly control the merging, splitting, and switching of the flow direction of the medium, but also close any channel to connect the other two channels. This type of valve should generally be installed horizontally in pipelines.

As professional ball valve suppliers, we provide comprehensive classifications to suit diverse industrial applications. Our custom-engineered ball valves strictly comply with DIN, JIS, API 6D and ASTM standards, ensuring superior performance across all categories. Key features include:

Temperature resilience: Operates reliably from -196°C to 800°C;

Unmatched stability: 80% higher durability than industry benchmarks;

Robust construction: Engineered for extreme pressure, corrosion, and abrasive media.

Whether you require floating, trunnion-mounted, V-port, or multi-port designs, our solutions deliver leak-proof security and 100,000+ cycle lifespans. Contact us for bespoke configurations matching your exact operational demands.
