Cast Steel Rising Stem Solid Wedge Gate Valve Class 600

JOEPAI has very extended experience in manufacturing of Cast Gate Valves. Our High Quality Cast Steel Rising Stem Solid Wedge Gate Valve Class 600 are designed, engineered and manufactured in strict conformance to API, ASTM, ASME, ANSI and other recognized standards.Cast Gate Valves can be divided into double gate, single gate, and elastic gate valves in wedge gate valves. Double gate wedge gate valve. This type of valve is commonly used in water and steam pipelines. The advantages of its structure are:

1. The accuracy requirement for the sealing surface angle is relatively low.
2. An increase in temperature is not likely to cause the phenomenon of wedging the gate.

When the sealing surface wears out, a gasket can be added to compensate.

Specification of Standards:

Design Rating:API600

Face to Face: AMSE B16.10

Flanged Ends: ASME B16.5

Inspection& Testing: API 598

Special: NACE MR-01-75 standard is workable;OEM/ODM;

Support customization.

Applicable Features

Bolted Bonnet or Pressure Seal Bonnet

Solid Wedge

Hard faced 13CR%,STL etc

Full Port

Outside Screw and Yoke (OS&Y), Rising Stem

Bolted bonnet,BB

Extended Bonnet For Cryogenic Services

Locking Device Optional

By pass on Request

Size: 2" up to 24"(DN50 up to DN600)

End Connection: Flanged RF, FF, RTJ, BW

Materials: Carbon Steel, Low Temperature Carbon Steel, Stainless Steel, Duplex Stainless Steel, Super Duplex Stainless Steel, Nickel Alloys, Nickel Aluminum Bronze, Hastelloy, Inconel Etc.

Operated by: Hand Wheel, Gear Op., Pneumatic, Hydraulic and Electric Actuator

Main parts materials

Main Dimensions
