CHINA JOEPAI manufacturer of 2-piece Korea type threaded ball valve. Available in SUS304(CF8), SUS316(CF8M) materials. Full port, anti-blowout stem, PTFE, RPTFE or PPL seat. Ideal for water, gas, oil, and chemical applications.
The 2-piece Korea type ball valve is a type of threaded (screw) end ball valve, widely used for on/off control of various media. As a compact and reliable solution, the threaded ball valve operates by rotating a ball with a cylindrical bore. The valve body connects to pipelines via internal threads (screw threads), ensuring easy installation and maintenance.
Compared with one-piece (monoblock) or three-piece designs, the two-piece structure offers a balanced combination of easy maintenance and leak-tight performance, making it the most popular choice for industrial applications.
The valve is operated manually (lever handle). Rotating the stem by 90° drives the ball to open or close:
Open position: ball bore aligned with pipe axis → media flows through.
Closed position: ball bore perpendicular to pipe axis → media is blocked.
Full port design – minimal pressure drop, easy pigging;
Two-piece body construction – easy to maintain, high reliability
Anti-blowout stem design – enhanced safety under pressure
Elastic ball sealing structure – reliable sealing even under temperature/pressure fluctuations
Investment casting – precise dimensions, smooth surface finish
Wide material selection – SS304, SS316, SS316L
Seat materials: PTFE, RPTFE (Reinforced PTFE), PPL – suitable for various media
Size range: DN6 – DN100 (1/4" – 4")
Pressure rating: JIS10K, JIS20K, 600WOG (PN40), 1000WOG (PN63)
Temperature range: -20°C up to 232°C
Our threaded ball valves support multiple international thread standards to meet global market requirements:
G (British Standard Pipe Parallel)
NPT (National Pipe Taper – US standard)
BSPT (British Standard Pipe Taper)
BSP (British Standard Pipe Parallel)
DIN259 / DIN2999 (German standard)
Normal Lever handle
Butterfly handle
Extended Height handle
This 2-piece Korea type threaded ball valve is widely used in the following fields:
Water treatment systems
Solvent transmission pipelines
Oxygen transport lines
Hydrogen peroxide pipelines
Ethylene production units
Natural gas distribution networks
Methane processing equipment
For special media such as oxygen, hydrogen peroxide, or flammable gases, special degreasing and cleaning processes are available upon request.
Our 2-piece Korea type ball valve is highly recognized in the following regions:
Korea
India
Russia
South Africa
China (domestic)
Precision investment casting – consistent quality, longer service life
Elastic sealing structure – compensates for wear and thermal expansion
Blowout-proof stem – enhanced operational safety
Full port design – no flow resistance
Flexible thread options – G, NPT, BSPT, BSP, DIN
Customization available – handle type, actuator mounting, special cleaning
If you decide to proceed with development, please send us your detailed inquiries. We will design accordingly and provide an accurate quotation based on your specifications.
✅ OEM & ODM accepted
✅ Small order quantity negotiable (depending on material)
✅ Fast delivery & factory price
